OTTICO Original - Made in Australia Since 1982
SPITWATER

HP15-210DE

Cold Water, Belt Drive, 15LPM, 3050 PSI, 9.5HP Kubota Diesel w Electric Start

From $9,500.00

Key Benefits
  • Non-Corrosive Pump Head: Ensures longer pump life and reduced maintenance costs.
  • Belt Drive Power Transmission: Efficient, strong, and reliable timing belt that uses less power than a gearbox.
  • Increased Efficiency: 15% more power available than a gearbox with maintenance-free operation.
  • Bypass Protection: Reduces potential damage to the pump during bypass mode.
  • Enhanced Portability: Pneumatic wheels offer greater manoeuvrability over tough terrain.
OTTICO Original - Made in Australia Since 1982
Download Spec Sheet
  • Overview
  • Technical Specifications
  • Downloads
Overview
SPITWATER
The HP15-210DE delivers 210 Bar pressure and 15 LPM flow, designed for industrial-grade cleaning.

OTTICO Original - Made in Australia Since 1982
Technical Specifications
Technical Specifications
Category Description Value
Features Machine Type Industrial
Features Duty Cycle Heavy
Features Temperature Cold
Features Drive Type Belt Drive
Features Nozzle Size 45
Performance Pressure (Bar) 210
Performance Pressure (MPa) 21
Performance Pressure (PSI) 3050
Performance Class Class A
Performance Country of Origin Australia
Performance Flow (L/Min) 15
Water Inlet Maximum Pressure (MPa) 1
Water Inlet Minimum Flow (L/min) 17
Water Inlet Maximum Temperature (°C) 40
Motor / Engine Motor / Engine Diesel
Motor / Engine Motor / Engine Brand Kubota
Motor / Engine Motor / Engine Model Kubota OC95
Motor / Engine Power (hp) 9.5
Motor / Engine Speed (rpm) 3570
Motor / Engine Fuel Capacity (L) 5.5
Motor / Engine Fuel Consumption (L/h) 2.39
Motor / Engine Motor / Engine - Oil Capacity (L) 1.5
Motor / Engine Motor / Engine - Oil Type 15W-40
Pump Pump Type Piston Pump
Pump Pump Brand Interpump
Pump Pump Model WS251
Pump Pump Oil Capacity (L) 1.1
Pump Pump Oil Type 15W-40
Bypass System Valve Model VRT3
Electrical Sound Power Level (dBA) 107
Values Determined as Per AS/NZS 60335.2.79 Sound Pressure Level (dBA) 99
Values Determined as Per AS/NZS 60335.2.81 Reaction Force on Spray Gun (N) 49.5
Dimensions & Weight Packed Height (mm) 930
Dimensions & Weight Packed Length (mm) 880
Dimensions & Weight Packed Weight (kg) 163
Dimensions & Weight Packed Width (mm) 770
Dimensions & Weight Unpacked Height (mm) 827
Dimensions & Weight Unpacked Length (mm) 875
Dimensions & Weight Unpacked Weight (kg) 140
Dimensions & Weight Unpacked Width (mm) 697
